• Tilton master cylinder 76-Series

    203.00 €
    In stock: 0 pcs
    Country
    USA
    Brand
    Tilton
    • Compact flange-mount master cylinder features dual outlet port options 3/8 x 24 (AN3) and one 7/16”-20 inlet port (AN4)

    • Flange mount onto pedal assemblies with 2.25” ( 57.15 mm ) center to center mounting studs

    • Aluminum alloy body is black anodized for corrosion resistance

    • 1.1” ( 27,94mm ) stroke

    • Dual AN3 outlet port options (rear and top). Top outlet port is deep for use with most banjo fittings

    • Rear outlet port is standard depth AN3 spec

    • 7/16”-20 inlet port

    • Fits Tilton 600-Series and 800-Series (clutch only) pedal assemblies/balance bars

    • 5/16”-24 pushrod



    More information  please find here:



    • Part number: 76-625 ( 5/8" (15.88mm)
    • Part number: 76-700 ( 7/10" (17.78mm)
    • Part number: 76-750 ( 3/4" (19.05mm)
    • Part number: 76-812 ( 13/16" (20.64mm)
    • Part number: 76-875 ( 7/8" (22.23mm)
    • Part number: 76-1000 ( 1" (25.40mm)
